OPERATION EXPLANATION OF COMPONENTS
3-15
DISPLAY PANEL A (SPEED RANGE, SET TRAVEL SPEED, SHIFT MODE INDICATOR)
This meter (6) indicates speed range, travel speed, and shift mode.
Use the shift mode switch (9) to select the shift mode.
Position (A): Quick shift mode
Pilot lamp (C) on display panel A lights up.
Position (B): Variable shift mode
Pilot lamp (D) on display panel A lights up.
