Kongsberg SIMRAD IS15 - Page 80

IS15 General Manual
78 20220760I
SIMR AD
Simrad
CE-Type
Chart Plotter/
Echo Sounder
or CA Multi-
function radar
*
SIMRA D
SIMRA D
*
12V Supply
**
**
Speed/temp
transducer
Depth
transducer
Autopilot J3000X Junction Unit
Junction box
(mast foot)
Wind
Transducer
**
SIMRA D
*
**
IS15 Power Supply
*
*
*
*
**
Roblink cable with connector
Optional extra
***
Only when using J300X
NMEA signal flow
***
1. 2. 3. 7.
0.3m (1').0.3m (1'). 0.3m (1').0.3m (1').
5m (16').
30m (100').
10m (33').
Figure 6-21 NMEA Repeaters using IS15 Power supply
SIMRAD
NMEA
source
12V supply
Figure 6-22 Single stand alone NMEA repeater
Note !
Refer to section 7.3 screen 4 or section 7.13 screen 6 for
instructions on Roblink turn-off.
