Kongsberg SIMRAD IS15 - IS15 Expander Installation Details

Installation
20220760I 77
SIMR AD
Simrad
CE-Type
Chart Plotter/
Echo Sounder
or CA Multi-
function radar
*
SIMR AD
SIMR A D
*
12V Supply
**
**
Speed/temp
transducer
Depth
transducer
Autopilot
J3000X
Junction
Unit
(Special) Roblink
Power Cable.
Junction box (mast foot)
2,5m (8')
Wind
Transducer
**
***
*
**
Roblink cable with connector
Optional extra
***
Only when using J300X
NMEA signal flow
1.
2.
3.
0.3m (1') 0.3m (1')
30m (100')
10m (33')
Figure 6-20 NMEA Repeaters using Roblink Power Cable
Refer to section 6.10 for information and cabling instructions. Also
refer to the note below Figure 6-12.
