8.2 Name of each Component
8
AccurioPress C2070series 8-8
7WARNING
NEVER throw the waste toner box into a fire.
- Otherwise, the toner may ignite and cause a dangerous situation.
7CAUTION
DO NOT touch the fusing part of the conveyance fixing unit. Otherwise, you may get burned.
- Please be especially careful in withdrawing the conveyance fixing unit or opening the fusing part.
7CAUTION
DO NOT put your hand or arm between the main body and the conveyance fixing unit.
- Touching connecting terminals of electric parts may damage the machine or cause unexpected trouble.
Please do not try to work yourself, but contact your service representative.
7CAUTION
DO NOT pull out the toner bottle other than the time to exchange for running out of toner.
- If you pull out the toner bottle in which the toner remains, an area nearby may become dirty with toner.
6 Lever [M1] Locks the conveyance fixing unit.
If a paper jam has been detected, push this lever down to
the left and pull out the conveyance fixing unit.
7 Fixing unit Fuses toner on paper by heat and pressure.
8 Side guide lock knobs Fixes the side guide plates.
9 Rear guide plate Aligned to the rear edge of loaded paper.
10 Side guide plates Aligned to the edges of loaded paper.
11 Feed roller Rotates when feeding paper into this machine.
12 Side guide lock release lever Pinch the tabs and push in this lever to release the lock
when moving the side guide plates.
