No. Name Description
1 Keypad Enter the values such as the number of copies or the zoom ratio.
2 Reset * Returns the contents you entered or changed on the control
panel to the default settings.
3 Power LED Lights up in red when the main power switch is turned on, then
lights up in green when the sub power switch is turned on.
4 Data LED Flashes when receiving a job.
5 Interrupt * Used to make an interrupt copy.
Using this function, you can interrupt the currently executed job
to prioritize a copy job when you want to make a copy on urgent
business. The Interrupt LED flashes until interrupt becomes
possible. When interrupt becomes possible, the Interrupt LED
lights up.
6 Stop Stops machine operations or erases the scanned image data.
7 Proof Copy * Used to make a proof copy.
Print data to check the adjusted image quality on the [Quality
Adjustment] screen, or output a sample from the [Job Ticket Ed-
it] screen.
8 Start Starts each function operation.
