7-21
7.4 Major Specifications
)Perfect Binder PB-503
Output tray Function
Perfect binding
Specifications
Paper weight Perfect binder tray
• Body set: 62 g/m
2
to 105 g/m
2
/ 16 lb Bond to 28 lb Bond
• Cover: 81 g/m
2
to 216 g/m
2
/ 22 lb Bond to 57 lb Bond
Secondary (sub) tray
•40 g/m
2
to 350 g/m
2
/ 11 lb Bond to 93 lb Bond
Paper size Perfect binder tray
•A4 v, B5 v, A5 w/v,
8.5 e 11 v, 5.5 e 8.5 w/v, 16K v
• Custom: Width 139 mm to 307 mm, Length 210 mm to 221 mm / Width 5.47"
to 12.09", Length 8.27" to 8.7"
• Cover: Width 139 mm to 307 mm, Length 279 mm to 472 mm / Width 5.47" to
12.09", Length 10.98" to 18.58"
Secondary (sub) tray
•SRA3 w, A3 w, B4 w, SRA4 w/v, A4 w/v, B5 w/v, A5 w/v, B6 w, A6 w,
13 e 19 w, 12 e 18 w, 11 e 17 w, 9 e 11 v, 8.5 e 14 w, 8.5 e 11 w/v, 7.25 e
10.5 w/v, 5.5 e 8.5 w/v, 8K w, 16K w/v
, Foolscap*
• Tab Paper: A4T v, 8.5 e 11T v
• Custom: Width 95 mm to 331 mm, Length 139 mm to 488 mm / Width 3.74" to
13.03", Length 5.47" to 19.21"
*Foolscap refers to 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w, or 8 e 13 w.
Number of sheets to be
bound
• Min. 10 sheets to max. 300 sheets, or within 30 mm / 1.18" thick
• Colored, Coated: max. 150 sheets, or within 15 mm / 0.59" thick
Maximum number of Z-folded insertions:
• 4 sheets or less for the duplex printing
• 2 sheets or less for the simplex printing
