SERVICE SCHEDULE CF5001 Field Service Ver.1.0 Sep 2003
4-14
IV SERVICE
1.7 Periodic check items (Cover Inserter D)
A. Periodic check (I) (Every 500,000 copies/prints)
B. Periodic check (II) (Every 1,000,000 copies/prints)
C. Periodic check (III) (Every 3,000,000 copies/prints)0
1.8 Periodic check items (TMG-3)
A. Periodic check (I) (Every 4,000,000 copies/prints)
No.
Classifica-
tion
Service item Quantity
Implementation classification
Materials•
Tools used
Clean-
ing
Check
Lubri-
cation
Replac
ement
1
Paper feed (1) Feed roller assembly /B
2 z
Actual durable
count: 100,000
(2) Double feed prevention
roller assembly
2 z
Actual durable
count: 100,000
No.
Classifica-
tion
Service item Quantity
Implementation classification
Materials•
Tools used
Clean-
ing
Check
Lubri-
cation
Replac
ement
1
Paper feed (1) Feed roller assembly /A
2 z
Actual durable
count: 200,000
No. Classification Service item Quantity
Implementation classification
Materials•
Tools used
Clean-
ing
Check
Lubri-
cation
Replac
ement
1
Paper feed (1) Torque limiter
2 z
Actual durable
count: 600,000
No. Classification Service item Quantity
Implementation classification
Materials•
Tools used
Clean-
ing
Check
Lubri-
cation
Replac
ement
1
Trimmer (1) Trimmer blade /U
1 z
Actual durable
count: 500,000
(2) Trimmer blade /L
1 z
Actual durable
count: 500,000
