Konica Minolta CM-25d - Specifications

140139
Appendix
6
Specifications
Model CM-26dG CM-26d CM-25d
Color
Illumination/
viewing system
di: 8°, de: 8° (diuse illumination: 8° viewing)
SCI (specular component included) / SCE (specular component excluded) switchable
Integrating sphere Ø54 mm
Detector Dual 40-element silicon photodiode arrays Dual 32-element silicon
photodiode arrays
Spectral
separation device
Planar diraction grating
Wavelength range 360 to 740 nm 400 to 700 nm
Wavelength pitch 10 nm
Half bandwidth Approx. 10 nm
Reflectance
measurement range
0 to 175%; Display resolution: 0.01
Light source Pulsed xenon lamp ×2 Pulsed xenon lamp ×1
(with UV cut filter)
Illumination area 12 × 12.5 mm
(circle + ellipse)
MAV : Ø12 mm
SAV : Ø6 mm
MAV : Ø12 mm
Measurement area MAV: Ø8 mm, SAV: Ø3 mm MAV : Ø8 mm
Repeatability Standard deviation within ΔE*ab 0.02 Standard deviation within
ΔE*ab 0.04
(When a white calibration plate is measured 30 times at 5-second intervals after white
calibration)
Inter-instrument
agreement
Within ΔE*ab 0.12 Within ΔE*ab 0.2
(Based on average for 12 BCRA Series II color tiles; MAV SCI; compared to values
measured with a master body under Konica Minolta standard measurement
conditions)
UV setting 100% / 0% / Adjusted (Instantaneous numerical
adjustment of UV with no mechanical filter movement
required)*
1
; 400 nm UV cuto filter
0% only; 400 nm UV cuto
filter
Observer 2° observer angle, 10° observer angle
Illuminant A, C, D50, D65, F2, F6, F7, F8, F10, F11, F12, ID50, ID65, User-defined illuminant
*2
(Simultaneous evaluation with two light sources possible)
Display items Colorimetric values/graph, color dierence values/graph, spectral graph, pass/fail
judgment, pseudocolor
Colorimetric
values
L*a*b*, L*C*h, Hunter Lab, Yxy, XYZ, and color dierence in these spaces; Munsell (C)
Indices MI, WI (ASTM E313-73),
YI(ASTM E313-73,
ASTMD1925),
ISObrightness (ISO 2470),
WI/Tint (CIE/Ganz),
Strength, Opacity,
GreyScale (ISO 105-A05),
User index
*2
MI, W (I ASTM E313-73),
YI(ASTM E313-73,
ASTMD1925),
ISObrightness (ISO 2470),
WI/Tint (CIE/Ganz),
Strength, Opacity,
GreyScale (ISO 105-A05),
8°gloss value, User index
*2
MI, W (I ASTM E313-73),
YI(ASTM E313-73,
ASTMD1925),
ISObrightness (ISO 2470),
WI/Tint (CIE), Strength,
Opacity,
Grey Scale (ISO105-A05),
8°glossvalue, User index
*2
Color dierence
equations
ΔE*ab (CIE1976) / ΔE94 (CIE1994) / ΔE00 (CIE2000) / CMC (l:c) / Hunter ΔE / DIN99o
Applicable standards ISO 7724/1, CIE No.15, DIN 5033 Teil 7, JIS Z 8722 Condition “c”
Gloss
Measurement angle 60° — —
Light source White LED — —
Detector Silicon photodiode — —
Color sensitivity Spectrally adjusted to CIE
photopic luminous
eciency V(λ) under CIE
illuminant C
— —
