MAV ø8mm
SAV ø3mm
For plastics, paints, resins and consumer products
For textile, paper, fluorescent and consumerproducts
For pharmaceuticals, cosmetics, printing, building materials, textiles etc.
Relativity Gloss Value
Numerical UV Control
Numerical Gloss Control
Expanded LCD display (64 x 240 dots)
Displays a large quantity of information
(simultaneous display of SCI and SCE data etc.)
High-accuracy sensor
Measures at 10nm intervals
for the full wavelength range.
Excellent repeatability
Easy-to-carry, compact
and lightweight
670g (without batteries)
In various applications
Powerful partnership between
CM-2600d and
Simultaneous measurement of SCI and SCE displays data on the LCD in 1.5 seconds. Unlike conventional spectrophotometers, there is no need
to switch between SCI and SCE mode. This improves working efficiency, and provides stable measured data since the measurement area does
not shift when the mode is switched. And also Relativity Gloss Value can be displayed by using Numerical Gloss Control.
• SCI is a method in which measurements are taken with
the specular reflection included. For this reason, it
minimizes influences of the surface condition of a sample,
and is especially suitable for color quality control and
Computer Color Matching.
• SCE is a method in which measurements are taken
excluding the specular reflection. For this reason, it
provides measurement results similar to those observed
by the human eye.
Light sources including and excluding UV component flash sequentially to provide
sample data taken with UV-included energy as well as UV-excluded energy
(UV400nm cutoff filter)
The battery-powered small, compact body allows the instrument to be placed in any position at the
sample surface.
The large LCD reverse video display provides easy reading, irrespective of which hand it is held in.
Using your finger, the
navigation wheel allows
simple and user-friendly
operation.
( Turn) ( Push)
The optics use an integrating sphere to provide diffuse
illumination/8-degree viewing system.
The CM-2600d conforms to all widely accepted industry standards
including ISO, JIS, DIN, CIE and ASTM, and generates
measurements in color spaces such as L*a*b*, Yxy, Munsell and CMC.
Example of data taken with UV-excluded energy Example of data taken after UV adjustment
Promotes accurate color communication.
Conforms to all widely accepted industry
standards and allows measurements in
all commonly used color spaces.
The instrument is portable and it allows
measurements to be taken using two
different areas of view (ø8mm and
ø3mm). The user can choose the most
suitable measurement area for the
target. The lightweight, easy-to-carry body
with the illuminated viewfinder enables
the user to position the instrument on the
target quickly and accurately.
Measures the target with
high accuracy.
Easy-to-carry stylish body with
an illuminated viewfinder.
Allows measurement in any position.
Compact, lightweight with an easy-to-operate navigation
wheel and large LCD display.
World's first portable spectrophotometer equipped
with instantaneous UV adjustment function.
UV evaluation time has been reduced
revolutionarily due to the introduction of
advanced Numerical UV Control.
Simultaneous measurement of SCI (specular component included) and SCE
(specular component excluded).
Advanced Numerical Gloss Control.
The number of moving parts used in the instrument is minimized through the
introduction of numerical control technology. The CM-2600d can be used with
confidence, since it has been developed, manufactured and calibrated to meet
ISO 9001 requirements.
High reliability and long life.
Maintenance-free design.
Light source for SCI
For paints, plastics, automobiles, ceramics, architectural interiors, textile, paper, food etc.
UV included
UV excluded
Finder
Mac OS 9.2J illustrator 10J
CM-2600d_inside.ai 2006.11.21
The CM-2600d is a portable integrating sphere spectrophotometer designed for
versatility in various applications.
UV adjustment function, data can be easily taken using the desired light source (e.g. D65, D50, C).
UV calibration can be performed simply by measuring a standard with known fluorescent values
under the desired light source.
Once the UV calibration is completed,
sample data can be taken by measuring
the sample under the desired light
source. Since the conventional UV
adjustment that requires the UV cutoff
filter to be moved is not necessary,
measurement time can be reduced
drastically.
(Note on UV-Adjustment : Numerical UV-
calibration requires for the adjustment
calculation
SpectraMagic
TM
NX
.)
Since the instrument has a
built-in instantaneous
The LCD specifications are subject to
change without prior notice.
Color Data Software
Light source for evaluation
of specular component
Illuminated viewfinder
d/8 integrating sphere optics that
conform to industry standards
SpectraMagic
TM
NX enables you to perform comprehensive color
inspection and analysis of incoming raw materials, in process
production, and outbound color critical goods and materials in
virtually any industry. With SpectraMagic
TM
NX you can insert digital
images with measured data. Measure samples in any of 8
universally accepted color spaces. Select from 15 illuminants, and
up to 40 indices to determine specific color and appearance
properties, such as strength, brightness, haze, yellowness, opacity
and strength. You can even configure up to 3 customized color
equations. Reports range from simple Pass/Fail to trend charts,
histograms, color plots, and spectral graphs. SpectraMagic
TM
NX
comes with predefined templates using skin technology, or you can
create your own templates. For illustrations and explanations to
understanding color and color measurement technology, there is a
link to Konica Minolta's well known and respected “Precise Color
Communication”. Step by step navigation help. SpectraMagic
TM
NX
conforms to FDA 21 CFR Part 11 assuring integrity and reliability of
data records.
•Windows
®
is a trademark of Microsoft Corporation in the USA and other countries.
(Optional)
Supports Windows
®
2000/XP
SpectraMagic
TM
NX
SpectraMagic
TM
NX
