Konica Minolta Drypro 832 - Ejection Unit; Main Unit

Chapter 18 Technical Information
18-13
18.2.6 Ejection Unit
Shows the placement of the mechanical components in the ejection unit.
18.2.7 Main Unit
Shows the placement of the mechanical components in the main unit.
No. Name Drawing
No.
Replacement
Procedures
1 Densitometer - Page 10-3
2 Ejection motor PM4 Page 10-3
No. Name Drawing
No.
Replacement
Procedures
1 Power supply (internal, external) cooling fan FM7 Page 11-17
2 Control cooling fan FM4 Page 11-25
