•Seatransport:IMDG

•Railway:RID

•Roadtransport:ADR

Note

Damagedsensorsthatarereturnedtothemanufacturerforrepairshallbetransported

withoutbatteries.Damagedorspentbatteriesthathavebeenrecalledbythe

manufacturerforsafetyreasonsshallnotbetransportedbyair.

SECTION15:Regulatoryinformation

Notapplicable.

SECTION16:Otherinformation

Thebatterymanufacturers’safetydatasheetsareavailableontheirwebsites.

•LithiumWerks:https://lithiumwerks.com

cNODEMiniSInstructionManual
