Kontron ETX-DC - Block Diagram

ETX-DC®/ Specifications
7
3.3 Block Diagram
CPU
N270
Diamondville
North Bridge
Intel 82945 GSE
South Bridge
Intel 82801 GBM
(ICH 7M)
X3 X1
X2
AGP VGA
Controller
Ethernet
MAC/PHY
Intel 82562V
HDA
Codec
ALC888
PCI to ISA
Bridge
ITE8888
Super I/O
Controller
Winbond
W83627HF
SPI
BIOS
Flash
I2C
CRT
LCD (JILI)
Ethernet
SMB
Floppy / LPT
PS/2
Serial/IrDA
HDA
SDVO Connector
SDVO
PCI
ISA
x2 DMI
LPC
SPI
USB 0-3
FAN
Connector J8
FSB533
X4
IDE
DDR-
SDRAM
DDR 533
ETX-DC
Serial IRQ
Watchdog
EEPROM
(CMOS
Setup Data)
RTC
LPC
LPC to ISA
Bridge
F85226FG
ISA
USB 4;5
USB
Connectors
J5;J6
SATA
SATA
Connectors
J3;J4
PCIe to
PATA
JMB368
PCIe
IDE
24 bit VESA
mapping
enabler
