Kontron ETX-DC - Connector X2 (ISA Bus)

ETX-DC®/ ETX® Connectors
16
Warning: Do not connect 3.3 V pins to external 3.3 V supply.
For additional information, refer to the ETX® Design Guide, I2C application notes, and JIDA specifications, all of
which are available on the Kontron Embedded Systems Web site.
4.4 Connector X2 (ISA Bus)
Pin
Signal
Pin
Signal
Pin
Signal
Pin
Signal
1
GND
2
GND
51
VCC *
52
VCC *
3
SD14
4
SD15
53
SA6
54
IRQ5
5
SD13
6
MASTER#
55
SA7
56
IRQ6
7
SD12
8
DREQ7
57
SA8
58
IRQ7
9
SD11
10
DACK7#
59
SA9
60
SYSCLK
11
SD10
12
DREQ6
61
SA10
62
REFSH#
13
SD9
14
DACK6#
63
SA11
64
DREQ1
15
SD8
16
DREQ5
65
SA12
66
DACK1#
17
MEMW#
18
DACK5#
67
GND
68
GND
19
MEMR#
20
DREQ0
69
SA13
70
DREQ3
21
LA17
22
DACK0#
71
SA14
72
DACK3#
23
LA18
24
IRQ14
73
SA15
74
IOR#
25
LA19
26
IRQ15
75
SA16
76
IOW#
27
LA20
28
IRQ12
77
SA18
78
SA17
29
LA21
30
IRQ11
79
SA19
80
SMEMR#
31
LA22
32
IRQ10
81
IOCHRDY
82
AEN
33
LA23
34
IO16#
83
VCC *
84
VCC *
35
GND
36
GND
85
SD0
86
SMEMW#
37
SBHE#
38
M16#
87
SD2
88
SD1
39
SA0
40
OSC
89
SD3
90
NOWS#
41
SA1
42
BALE
91
DREQ2
92
SD4
43
SA2
44
TC
93
SD5
94
IRQ9**
45
SA3
46
DACK2#
95
SD6
96
SD7
47
SA4
48
IRQ3
97
IOCHK#
98
RSTDRV
49
SA5
50
IRQ4
99
GND
100
GND
Notes: *To protect external power lines of peripheral devices, make sure that:
- The wires have the right diameter to withstand the maximum available current.
- The enclosure of the peripheral device fulfils the fire-protection requirements of IEC/EN60950
** IRQ9 is used for SCI in ACPI mode. Do not use for legacy ISA devices.
