ETX-DC®/ System Resources
40
8 System Resources
8.1 Interrupt Request (IRQ) Lines
8.1.1 In 8259 PIC mode
IRQ #
Used For
Available
Comment
0
Timer0
No
1
Keyboard
No
2
Slave 8259
No
3
COM2
No
Note (1)
4
COM1
No
Note (1)
5
LPT2
Yes
Note (2)
6
Floppy Drive Controller
No
Note (1)
7
LPT1
No
Note (1)
8
RTC
No
9
SCI
No
Note (3)
10
COM3
Yes
Note (2)
11
COM4
Yes
Note (2)
12
PS/2 Mouse
No
Note (1)
13
FPU
No
14
IDE0
No
Note (1)
15
IDE1
No
Note (1)
Note: 1 If the “Used For” device is disabled in setup, the corresponding interrupt is available for other devices.
2 Unavailable if baseboard is equipped with an I/O controller SMC FDC37C669, and the device is enabled in
setup.
3 Unavailable in Advanced Configuration and Power Interface (ACPI) mode. Used as System Control Interrupt
(SCI) in ACPI mode. Currently not free in Non-ACPI mode.
