Kontron KTQ67/Flex - Page 22

KTQ67 Users Guide
KTD-N0829-D Page 22
High Power Setup results:
DOS Idle, Mean, No external load
Supply
Current draw
Power consumption
+12V
1.978A
23.737W
+12V P4
1.827A
21.924W
+5V
2.061A
10.306W
+3V3
1.032A
3.404W
-12V
0.032A
0.384W
5VSB
0.006A
0.030W
Total
59.8W
Windows 7, mean
3DMARK2005 (first scene) & BiT 6
Supply
Current draw
Power consumption
+12V
3.115A
37.380W
+12V P4
4.957A
59.484W
+5V
2.457A
12.285W
+3V3
1.659A
5.475W
-12V
0.038A
0.456W
5VSB
0.006A
0.030W
Total
115.1W
S1 Mode, Mean, No external load
Supply
Current draw
Power consumption
+12V
2.179A
26.144W
+12V P4
0.594A
7.128W
+5V
1.076A
5.380W
+3V3
1.348A
4.447W
-12V
0.043A
0.516W
5VSB
0.006A
0.030W
Total
43.6W
S3 Mode, Mean, No external load
Supply
Current draw
Power consumption
+12V
0A
0W
+12V P4
0A
0W
+5V
0A
0W
+3V3
0A
0W
-12V
0A
0W
5VSB
0.364A
1.820W
Total
1.82W
S4 Mode, Mean, No external load
Supply
Current draw
Power consumption
+12V
0A
0W
+12V P4
0A
0W
+5V
0A
0W
+3V3
0A
0W
-12V
0A
0W
5VSB
0.295A
1.475W
Total
1.48W
System Specification
