Kontron KTQ67/Flex - Advanced - Displayblock Setup

KTQ67 Users Guide
KTD-N0829-D Page 96
9.5.15 Advanced - Displayblock Setup
Aptio Setup Utility – Copyright © 2011 American Megatrends, Inc.
Advanced
Displayblock Setup
LCDVCC Voltage
Backlight Signal Inversion
[3V3]
[Disabled]
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright © 2011 American Megatrends, Inc
Function Selection Description
LCDVCC Voltage
3V3
5V
Set the LVDS Display Panel voltage to either
3.3V or 5V.
Backlight Signal Inversion
Disabled
Enabled
Select Disabled if BKLTEN# signal (available
in the LVDS connector), shall behave
normally: active low to enable backlight.
Select Enabled if BKLTEN# signal shall
behave inversed: active high to enable
backlight.
BIOS - Advanced
