9.5.14 Advanced - LAN Configuration
Aptio Setup Utility – Copyright © 2011 American Megatrends, Inc.
Advanced
LAN Configuration
Control of Ethernet Devices and
PXE boot. To disable ETH1, ME
Subsystem must be as well.
ETH2 can not be disabled.
ETH1 Configuration (Left)
MAC Address & Link status:
ETH2 Configuration (Upper)
MAC Address & Link status:
[Enabled]
00E0F4271849+
[Enabled]
00E0F427184A-
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright © 2011 American Megatrends, Inc
Function Selection Description
ETH1 Configuration (Left)
Disabled
Enabled
With PXE boot
Control of Ethernet Devices and PXE boot.
To disable ETH1, ME Subsystem must be as
well. ETH2 can not be disabled.
ETH2 Configuration
(Upper)
Enabled
With PXE boot
Control of Ethernet Devices and PXE boot.
To disable ETH2, ME Subsystem must be as
well. ETH2 can not be disabled.
