9.5.1 Advanced - PCI Subsystem Settings
Aptio Setup Utility – Copyright © 2011 American Megatrends, Inc.
Advanced
PCI Bus Driver Version V 2.04.00
════════════════════════════════
In case of multiple Option
ROMs (Legacy and EFI
Compatible), specifies what PCI
Option ROM to launch.
PCI Option ROM Handling
PCI ROM Priority
PCI Common Settings Settings
PCI Latency Timer
VGA Palette Snoop
PERR# Generation
SERR# Generation
► PCI Express Settings
[EFI Compatible ROM]
[32 PCI Bus Clocks]
[Disabled]
[Disabled]
[Disabled]
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright © 2011 American Megatrends, Inc
Function
Selection
Description
PCI ROM Priority
Legacy ROM
EFI Compatible ROM
In case of multiple Option ROMs (Legacy
and EFI Compatible), specifies what PCI
Option ROM to launch.
PCI Latency Timer
32 PCI Bus Clocks
64 PCI Bus Clocks
96 PCI Bus Clocks
128 PCI Bus Clocks
160 PCI Bus Clocks
192 PCI Bus Clocks
224 PCI Bus Clocks
248 PCI Bus Clocks
Value to be programmed into PCI Latency
Timer Register.
VGA Palette Snoop
Disabled
Enabled
Enables or Disables VGA Palette Registers
Snooping.
PERR# Generation
Disabled
Enabled
Enables or Disables PCI Device to Generate
PERR#.
SERR# Generation
Disabled
Enabled
Enables or Disables PCI Device to Generate
SERR#.
