Kontron KTQ67/Flex - Page 79

KTQ67 Users Guide
KTD-N0829-D Page 79
The below description is only when SATA Mode = RAID Mode.
Aptio Setup Utility – Copyright © 2011 American Megatrends, Inc.
Advanced
SATA Configuration
SATA Mode
SATA Port0
Hot Plug
SATA Port1
Hot Plug
SATA Port2
Hot Plug
SATA Port3
Hot Plug
SATA Port4
Hot Plug
SATA Port5
Hot Plug
[RAID Mode]
Not Present
[Disabled]
Not Present
[Disabled]
Not Present
[Disabled]
Not Present
[Disabled]
Not Present
[Disabled]
Not Present
[Disabled]
(1) IDE Mode. (2) AHCI Mode.
(3) RAID Mode.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright © 2011 American Megatrends, Inc
Function Selection Description
SATA Mode
IDE
ACHI
RAID
(1) IDE Mode. (2) AHCI Mode. (3) RAID
Mode.
Hot Plug
Disabled
Enabled
SATA Ports Hot Plug Support
BIOS - Advanced
