9.5.10.1 Serial Port 3 Configuration
Note1: only if Serial Port = Enabled
Aptio Setup Utility – Copyright © 2011 American Megatrends, Inc.
Advanced
Serial Port 3 Configuration
Serial Port
Device Settings
Change Settings
Device Mode
[Enabled]
IO=3E8h; IRQ=7;
[Auto]
[Standard Serial Po…]
Enable or Disable Serial Port
(COM)
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright © 2011 American Megatrends, Inc
Function Selection Description
Serial Port
Disabled
Enabled
Enable or Disable Serial Port (COM)
Change Settings Note1
Auto
IO=3E8h; IRQ=7;
IO=3F8h; IRQ=3,4,5,6,7,10,11,12;
IO=2F8h; IRQ=3,4,5,6,7,10,11,12;
IO=3E8h; IRQ=3,4,5,6,7,10,11,12;
IO=2E8h; IRQ=3,4,5,6,7,10,11,12;
Select an optimal setting for Super
IO device.
Device Mode Note1
Standard Serial Port Mode
IrDA 1.0 (HP SIR) Mode
ASKIR Mode
Change the Serial Port mode. Select
<High Speed> or <Normal mode>
mode.
BIOS - Advanced
