9.5.10.3 Parallel Port Configuration
Note1: only if Parallel Port = Enabled
Aptio Setup Utility – Copyright © 2011 American Megatrends, Inc.
Advanced
Parallel
Port Configuration
Parallel Port
Device Settings
Change Settings
Device Mode
[Enabled]
Reset Required
[Auto]
[Standard Parallel ...]
Enable or Disable Parallel Port
(LPT/LPTE)
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright © 2011 American Megatrends, Inc
Function
Selection
Description
Parallel Port
Disabled
Enabled
Enable or Disable Parallel Port
(LPT/LPTE)
Change Settings Note1
Auto
IO=378h; IRQ=5;
IO=378h; IRQ=7,10,11,12;
IO=278h; IRQ=5,6,7,10,11,12;
IO=3BCh; IRQ=5,6,7,10,11,12;
IO=378h;
IO=278h;
IO=3BCh;
Select an optimal setting for Super
IO device.
Device Mode Note1
Standard Parsllel Port Mode
EPP Mode
ECP Mode
EPP Mode & ECP Mode
Change the Printer Port mode.
BIOS - Advanced
