WATER SUPPLY AND DRAIN LINE SIZING/
CONNECTIONS
Location
Water
Temperature
Water
Pressure
Ice Machine
Fitting
Tubing Size Up to
Ice Machine Fitting
Ice Making
Water Inlet
33°F (0.6°C) min.
90°F (32.2°C) max.
20 psi (1.38 bar) min.
80 psi (5.5 bar) max.
3/8" Female
Pipe Thread
3/8" (9.5 mm) min.
inside diameter
Ice Making
Water Drain
1/2" Female
Pipe Thread
1/2" (13 mm) min.
inside diameter
Condenser
Water Inlet
33°F (0.6°C) min.
90°F (32.2°C) max.
20 psi (1.38 bar) min.
150 psi (10.3 bar) max.
3/8" Female
Pipe Thread
3/8" (9.5 mm) min.
inside diameter
Condenser
Water Drain
— —
1/2" Female
Pipe Thread
1/2" (13 mm) min.
inside diameter
