Operational Analysis 1 2  4
Harvest Valve
The harvest valve
inlet is
HOT
and
The compressor
discharge line is
HOT
The harvest valve
inlet is
COOL
and
The compressor
discharge line is
HOT
The harvest valve
inlet is
COOL
and
The compressor
discharge line is
COOL
The harvest valve
inlet is
COOL
and
The compressor
discharge line is
HOT
Discharge Line Temp.
Record freeze cycle discharge
line temp at the end of freeze
cycle.
Discharge line temp
 at
the end of freeze cycle
Discharge line temp
 at
the end of freeze cycle
Discharge line temp
 at
the end of freeze cycle
Discharge line temp
 at
the end of freeze cycle
Final Analysis
Enter total number of boxes
checked in each column.
Harvest Valve
Leaking
Low On Charge
-or-
TXV Starving
TXV Flooding Compressor
