Refrigeration Component Diagnostic Chart
Operational Analysis 1 2 4
Ice Production Published 24 hour ice production________________
Calculated (actual) 24 hour ice production_______________
NOTE: The ice machine is operating properly if the ice fill pattern is normal and ice production is within
10% of charted capacity.
Installation and Water
System
All installation and water related problems must be corrected
before proceeding with chart.
