Korg D16XD User Manual

183
Appendices
TroubleshootingVarious messages
More about drives
and files
Installing the
options
Specifications
Various listsGlossaryIndex
<General>
■ Principal specifications
■ Analog/digital input and output spec-
ifications
<INPUT 1–8>
<INPUT 9–16>
<ANALOG COMPRESSOR>
<GUITAR INPUT>
<MASTER OUTPUT L/R>
Display: 320 × 240 pixel, four-level grayscale
Movable LCD with backlight and touch
panel
Power supply: AC Local Voltage
Power consumption:
D32XD: 98 W
120 W (AIB-8, ACB-8, DIB-8 is installed)
D16XD: 56 W
70 W (AIB-8, ACB-8, DIB-8 is installed)
Dimensions: 682 mm (W) × 474 mm (D) × 185 mm (H)
26.85" (W) × 18.66" (D) × 7.28" (H) (including
protrusions)
Weight:
D32XD
13.5 kg/39.76 lbs
14 kg/30.86 lbs (when the AIB-8, ACB-8
and DIB-8 is installed
)
D16XD
12 kg/26.46 lbs
12.5 kg/27.56 lbs (when the AIB-8, ACB-8
and DIB-8 is installed
)
Frequency response:
10 Hz – 20 kHz ±1 dB
@ fs 44.1 kHz, +4 dBu, 10 kΩ load
10 Hz – 22 kHz ±1 dB
@ fs 48 kHz, +4 dBu, 10 kΩ load
10 Hz – 44 kHz ±1 dB
@ fs 96 kHz, +4 dBu, 10 kΩ load
S/N: 103 dB (typical)
Dynamic range: 103 dB (typical)
THD+N: 0.02% (typical) 20 Hz–20 kHz
+16 dBu,10 kΩ load
A/D conversion: 24-bit 64 times oversampling
D/A conversion: 24-bit 128 times oversampling
Sampling frequency
Internal: 44.1 kHz, 48 kHz, 96 kHz
External: 44.1 kHz±6%, 48 kHz±6%,
96 kHz±6%
Record/Playback bit:
16-bit, 24-bit
Connectors: XLR-3-31 type (+48 V phantom power,
switchable), 1/4" TRS phone jack (balanced)
Input impedance: 4 kΩ (XLR-3-31), 10 kΩ (TRS phone jacks)
Nominal level: –60 dBu to –12 dBu @ TRIM=max. – min.
PAD OFF
–34 dBu to +14 dBu @ TRIM=max. – min.
PAD ON
Maximum level: –48 dBu to 0 dBu @ TRIM=max. – min.
PAD OFF
–22 dBu to +26 dBu @ TRIM=max. – min.
PAD ON
Source impedance: 600 Ω
* If the 8-channel analog input board (AIB-8) is installed
Connectors: 1/4" TRS phone jack (balanced)
Input impedance: 10 kΩ
Nominal level: –60 dBu to –12 dBu @ TRIM=max. – min.
PAD OFF
–34 dBu to +14 dBu @ TRIM=max. – min.
PAD ON
Maximum level: –48 dBu to 0 dBu @ TRIM=max. – min.
PAD OFF
–22 dBu to +12 dBu @ TRIM=max. – min.
PAD ON
Source impedance: 600 Ω
Threshold level: 0 to –40 dB
Ratio: 1.5:1 to inf:1
Attack time: 1 to 200 mS
Release time: 10 mS to 10 S
Out gain: ±20 dB
Connector: 1/4" phone jack (unbalanced)
Input impedance: 1 MΩ
Nominal level: –60 dBu to –12 dBu @ TRIM=max. – min.
PAD OFF
–34 dBu to +14 dBu @ TRIM=max. – min.
PAD ON
Maximum level: –48 dBu to 0 dBu @ TRIM=max. – min.
PAD OFF
–22 dBu to +12 dBu @ TRIM=max. – min.
PAD ON
Source impedance: 600 Ω
Connectors: 1/4" phone jack (balanced)
Output impedance: 150 Ω
Nominal level: +4 dBu
Maximum level: +16 dBu
Load impedance: 10 kΩ or higher
