16
g: List button
When you press this button, a menu list will appear, allow-
ing you to select an item from this list.
h: Scroll bar/scroll buttons
Use these to move up and down through a list of parameter
values that extends beyond the window in the display.
i: Confirmation button
When you press this button, a dialog box will open, asking
whether you are sure you want to execute the settings or
the operation. Some dialog boxes may contain an edit cell
for you to specify a value.
Press the Yes (or OK) button or the No (or Cancel) button in the dialog box to
close the dialog box and return to the previous tab page.
j: Radio buttons
Use the radio buttons to chose one of the displayed items.
k: Toggle button
This type of button will either change function or toggle between on/off each
time you press it.
l: Check box
Each time you press one of the check boxes, a check mark will either be added
or removed. Add a check mark if you want to enable that function.
* Other
In addition to the items listed above, the Drive button will open a dialog box
where you can select a drive for editing, and the Rename button will open a
dialog box where you can rename a song or program.
There are also certain screens, such as the routing confirmation screen, that
provide valuable information, but contain no editable items.
Menu list
g: List button
h: Scroll buttons
h: Scroll bar
k: Toggle button
i:Confirmation
button
l: Check box
Confirmation dialog box
j: Radio buttons
Drive button Rename button
