12
multisample play backward. Preset multisamples that have
a loop setting and RAM multisamples for which you’ve
made loop settings in Sampling mode will play backward in
one-shot mode. Multisamples that are already set to Reverse
will simply play back that way.
On (checked): The multisample will playback in reverse.
Off (unchecked): The multisample will playback normally.
Lvl (High Level) [000…127]
Specifies the level of the multisample.
Depending on the multisample, high settings of this
parameter may cause the sound to distort when a chord
is played. If this occurs, lower the level.
The playback level for a RAM multisample is also
affected by the “+12 dB” (Sampling P2: 2–1c) setting for
each sample. If the “+12 dB” setting is on, the playback
will be approximately +12 dB louder. (☞0–3C)
Low:
Here you can assign the Low multisample for OSC1.
The multisample you select here will sounded by velocities
less than the value of the “Velocity M.Sample SW Lo→Hi”
(1–2c) parameter “OSC1.”
Low MS Bank [ROM, RAM, Piano...Synth]
Low Multisample [refer to High Multisample table]
S.Offset (Low Start Offset) [Off, On]
Rev (Low Reverse) [Off, On]
Lvl (Low Level) [000…127]
☞ For details on the “Low” parameters, refer to the explana-
tions for the corresponding “High” parameters.
Octave [–2[32’], –1[16’], +0[8’], +1[4’]]
Adjusts the pitch in octave units. The normal octave of the
multisample is pitched at 8' (feet).
Transpose [–12…+12]
Adjusts the pitch in semitone steps over a range of ±1
octave.
Tune [–1200…+1200]
Adjusts the pitch of the sample in one-cent steps (a semitone
is 100 cents) over a range of ±1 octave.
Delay [0ms…5000ms, KeyOff]
Specifies a delay time from note-on until the note will sound.
With a setting of KeyOff, the sound will begin when note-off
occurs. This is used to create sounds such as the “click” that is
heard when a harpsichord note is released. In this case, set the
Amp1 EG, Amp2 EG (4–3a, 4–6) “Sustain” parameter to 0.
1–2b: OSC2 Multisample
This will appear when “Oscillator Mode” (1–1a) is set to
Double.
For details on the settings and function of the parameter,
refer to “1–2a: OSC1 Multisample.”
1–2c: Velocity M.Sample SW Lo → Hi
(Velocity Multisample Switch Low → High)
OSC1 (OSC1 Velocity Switch) [1…127]
The High and Low multisamples selected for oscillator 1 in
“OSC 1 Multisample” (1–2a) will be switched at the veloc-
ity value that you specify here.
Notes played with a velocity stronger than this value will be
sounded by the High multisample.
OSC2 (OSC2 Velocity Switch) [1…127]
This will appear when “Oscillator Mode” (1–1a) is set to
Double.
The High and Low multisamples selected for oscillator 2 in
“OSC 2 Multisample” (1–2b) will be switched at the veloc-
ity value that you specify here.
Notes played with a velocity stronger than this value will be
sounded by the High multisample.
1–2d: Drum Kit
Drum Kit [000(A/B)...143(User), 144(GM)...152(GM)]
Selects a drum kit.
*For 000 (A/B)–143 (User), you can use Global P5: Drum Kit to edit
the instrument assignments.
Octave [–2[32’], –1[16’], +0[8’], +1[4’]]
Adjusts the pitch in octave units. When using a drum kit, set
the Octave to 8'.
When editing a drum program, you must set this
parameter to 8'. With other settings, the sounds of the
drum kit will be assigned to the wrong notes of the key-
board.
Transpose [–12…+12]
This adjusts the location of the instruments in the selected
drum kit. Unless you need to change this, leave it at 0.
Tune [–1200…+1200]
This adjusts the pitch in one-cent units.
The pitch of each drum kit can be adjusted in Global P5:
Drum kit.
Delay (Delay Time) [0ms…5000ms, KeyOff]
This specifies a delay time from note-on until the sound will
begin.
With a setting of KeyOff, the sound will begin when note-
off occurs. In this case, set the Amp EG (4–3a) parameter
“Sustain” to 0.
000(IA/B)–015(A/B) TRITON Classic preloaded drum kits
016(H)...031(H)
032(I)...047(I)
048(J)...063(J)
064(K)...079(K)
080(L)...095(L)
096(M)...111(M)
112(N)–127(N)
128(User)–143(User)
Preloaded drum kits:
016(H)...045(I), 128(User)...131(User)
User drum kits
144(GM)–152(GM) ROM preset drum kits compatible with GM2
