© 2020 KOSTAL Solar Electric GmbH
You can find this installation guide in our download area for the PIKO MP plus under Operating
manual.
The installation guide does not replace the operating instructions or manuals for the inverter,
battery and KOSTAL Smart Energy Meter required for correct assembly and installation.
IMPORTANT INFORMATION
Installation may only be carried out by a trained and qualified electrician!
Follow the safety instructions in the operating instructions for the inverter, battery and KOSTAL
Smart Energy Meter.
A battery activation code for the KOSTAL Smart Energy Meter and a computer / tablet are requi-
red to put the storage system into full operation and to make all the necessary settings.
For all work on the devices or on the supply lines, the power supply in the house, the inverter and
the battery must be completely de-energized. Take a look at the corresponding operating inst-
ructions for the respective devices (inverter / battery / KOSTAL Smart Energy Meter).
PIKO MP plus applications
The PIKO MP plus can be used as a PV inverter, battery inverter or as a hybrid inverter with and without
a battery.
PIKO MP plus da 1.5 a 3.6 con 1 inseguitore MPP PIKO MP plus da 3.0 a 5.0 con 2 inseguitori MPP
KOSTAL Smart
Energy Meter
KOSTAL Smart
Energy Meter
KOSTAL Smart
Energy Meter
KOSTAL Smart
Energy Meter
KOSTAL Smart
Energy Meter
1)
Battery inverter
PIKO MP plus 1.5 to 3.6 with 1 MPP tracker PIKO MP plus 3.0 to 5.0 with 2 MPP trackers
PV inverter PV inverter Hybrid inverter Battery inverter
1) Second DC input not connected.
Installation guide
