your home. More information on each of the modes is provided later.
Figure 18, Mode selection.
a. “AUTO” Mode: With the switch in this position, your heater will turn
itself on and off based on an externally wired switch. The most
common use of this mode is with a wall thermostat. When wired to a
wall thermostat, the heater will automatically light itself when the room
temperature falls below the thermostat setting and will automatically
turn itself off when the temperature reaches the thermostat setting. This
mode can also be used with a wall switch or remote controls. Consult
your local dealer or visit WWW.KOZISTOVES.COM for more
information on available options.
Switch Position
Igniter
Required
Thermostat
Required
Description
AUTO* Yes Yes
Turns Heater ON and OFF based on wall thermostat,
remote control, wall switch or other switching device.
HIGH/LOW Optional Yes
Switches heater from user setting to factory LOW setting
based on wall thermostat, remote control, wall switch or
other switching device.
MANUAL Optional No
Relies on a person to press the ON/OFF button located on
the control pannel. Will automatically light if equiped with
electric igniter.
Mode Selection Guide
* CAUTION: May result in shortened igniter life. See complete mode description.
Please note that “AUTO” mode, when used in conjunction with a wall
thermostat, can result in “reduced” igniter life. Always use your stove on
the lowest possible heat setting when in this mode. This will help reduce
the number of ignition cycles and will help prevent premature igniter
failure.
b. “HIGH/LOW” Mode: With the switch in this position, your heater will
alternate from a
factory preset low to the setting you have chosen with
the “HEAT SELECT” button (see {“HEAT SELECT: Button} section
for more information). This mode is almost exclusively used with a wall
thermostat and is highly recommended since it can create substantial fuel
savings. This mode does not need an electric igniter. If an electric
igniter is installed, the heater will automatically light itself when it is first
turned on. If no electric igniter is installed, the fire will need to be lit
manually (see “Starting (lighting) your Heater” section).
c. “MANUAL” Mode: When used in this mode, your stove is controlled
from the control panel only. Although an electric igniter can be used in
this mode, it is not required. When the heater is the “MANUAL” mode,
the heater will not respond to any external switch (Thermostat). If an
electric igniter is installed, the heater will automatically light itself when it
is first turned on. If no electric igniter is installed, the fire will need to be
lit manually (see “Starting (lighting) your Heater” section).
