KRAL DKC Series - 5 Function description; Structure; Functional principle

5 Function description
5.1 Structure
5 Function description
5.1 Structure
9
10
1
2
3
4
8
7
2
3
6
5
Fig.3: Structure of pump station
1 Station block 5 Reversing valve lever 8 Pump
2 Lifting lug 6 Pressure-side pressure
gauge
9 Pressure connection
3 Suction-side pressure
gauge
7 Loosen the screw plug of
the vent hole
10 Suction connection
4 Strainer cover
PI
PI
PI
M
M
LFO
HFO
Suction Side
Pressure Side
TI
TI
Fig.4: Hydraulic scheme
12
