8 Installation, removal
8.3 Mounting the pump station
18
195
115
280
A
18
325
190
144,5
B
Fig.10: Montage auf Grundrahmen mit Ölwanne
100
132
18
A
B
80 50
140
18
Fig.11: Bracket mounting
A Large pump station
B Small pump station
Requirement:
ü Pump station connections protected against soiling, for example by using the protective cover
mounted in the factory
1. Bring the pump station into the installation position.
2. Fasten the pump station with fastening elements securely on the underground.
3. After the connecting work clean the pipe system thoroughly Ä Commissioning,Page30.
