BA 35203_04 * 3.0 * 35203_04_04_Inbetriebnahme_04.fm 4-43
Putting into operation 4
Machine status indication on indicating instrument (HMI)
In order to access the “HMI” status indication, press the touch button 61
repeatedly.
➥ Contains indications (data) on the indicating instrument.
Machine status indication on engine control unit (ECU)
• In order to call the “ECU” status indication, press push button 61
repeatedly.
• To access the display of the axle and soot load of the diesel particulate
filter, press the touch button 62
– see chapter 7 “Exhaust gas treatment” on page 7-73.
• To access the display of the fill level of the urea solution, press touch
button 62 repeatedly – see chapter 7 “Monitoring of the SCR catalytic
converter: Fill level of urea solution” on page 7-80.
• To access the display of the fuel consumption, press touch button 62
repeatedly.
Machine status indication on cabin controller (VCU)
In order to access the “VCU” status display, press the touch button 61
repeatedly.
➥ Contains indications (data) on the cabin controller.
xxxxxxxxxx
Fig. 83
HMI
xxxxxxxxxx
xxxxxxxxxx
xxxxxxxxxx
xxxxxxxxxx
61
Fig. 84
62
61
ECU
%___DEF
ECU
x.x l/h
62
62
ECU
%___Ash
%___Soot
ECO
Fig. 85
VCU
61
xxxxxxxxxx
xxxxxxxxxx
xxxxxxxxxx
xxxxxxxxxx
xxxxxxxxxx
