9 Technical data
Payload with pallet forks (SKID STEER quickhitch)
Payload (500 mm (19.68 in)
load distance)
352-04S / 352-04L
Payload (A)
safety factor 1.25
2500 kg (5511.6 lb)
Payload (B)
safety factor 1.67
1850 kg (4078.6 lb)
Movable payload
1
Transport position:
Safety factor 1.25
1. The movable payload is only authorized in transport position of the loader unit, and is not specified in
the load diagram. The values may be limited by the permissible load-bearing capacity of the pallet forks
/ fork arms.
3250 kg (7164.9 lb)
Movable payload
1
Transport position:
Safety factor 1.67
2400 kg (5291.0 lb)
