Kramer 840Hxl

10
840Hxl - Operating the 840Hxl Pattern Generator
User Defined Resolutions
Resolution
Resolution
720 x 480 @120Hz
2880 x 480 @60Hz
720 x 480 @240Hz
2880 x 480i @60Hz
720 x 576 @50Hz
2880 x 576 @50Hz
720 x 576 @100Hz
2880 x 576i @50Hz
720 x 576 @200Hz
1920 x 1080 @25Hz
1440 x 576 @50Hz
1920 x 1080 @30Hz
1440 x 576i @50Hz
1920 x 1080 @50Hz
1280 x 720 @50Hz
1920 x 1080i @50Hz
1280 x 720 @60Hz
1920 x 1080 @60Hz
1280 x 720 @100Hz
1920 x 1080i @60Hz
1280 x 720 @120Hz
1920 x 1080i @100Hz
1440 x 288 @50Hz
1920 x 1080i @120Hz
1440 x 480 @60Hz
2K 2048 x 1080 @50Hz
2880 x 240 @60Hz
2K 2048 x 1080 @60Hz
2880 x 288 @50Hz
The following patterns are supported.
#
Pattern
#
Pattern
1
100% Color bar
17
Square
2
75% Color bar
18
White dot
3
Gray 8
19
Alternate pixels
4
Red screen
20
White HScroll
5
Green screen
21
White VScroll
6
Blue screen
22
Multiburst
7
Yellow screen
23
Horizontal split
8
Cyan screen
24
Vertical split
9
Magenta screen
25
Red ramp
10
Gray 16
26
Green ramp
11
White screen
27
Blue ramp
12
RGB ramp
28
Bounce
13
Crosshatch black
29
Window
14
Crosshatch red
30
White border
15
Crosshatch green
31
Target circle
16
Crosshatch blue
32
Moving ball
