Kramer 840Hxl

840Hxl - Operating the 840Hxl Pattern Generator
11
11
The output options in the following table are supported.
Parameter
Front Panel
Values
Signal Mode
H/D
HDMI (video, audio and data
packet), DVI (video only), Auto
HDCP
HDCP
On, Off
Color Space
CS
RGB, YUV 444, YUV 422, Auto
Color Depth
DC
24 bit, 30 bit, 36 bit, Auto
Audio Sample Rate
ASF
44kHz, 48kHz, 88kHz, 96kHz,
176kHz, 192kHz, Auto
Audio Sample Depth
ASD
16 bit, 20 bit, 24 bit, Auto
6.1 Operating the 840Hxl Using the Front Panel Buttons
To activate the top row of functions (RES, PAT, CS and H/D):
 Press the Function ON/OFF button (the button LED lights)
To activate the bottom row of functions (HDCP, DC, ASF and ASD):
 Press the Function ON/OFF button again (the button LED no longer lights).
To select a function and modify the value, for example, to select a specific
pattern:
1. Press the Function button.
The button lights to indicate the top row of functions (ON) is active.
2. Press the PAT/DC button.
The button lights to indicate that the Pattern function is active.
3. Press the + or – button to cycle through the list of available patterns until the
required pattern is displayed on the 7-segment display.
Note: The display flashes if there is a problem communicating with the display, for
example, if the display does not support HDCP or does not support the selected
resolution.
