6 Operating the 840Hxl Pattern Generator
The 840Hxl can be operated either using the front panel buttons (see Section 6.1)
or using the 840Hxl Control Application (see Section 6.2).
The 840Hxl Control Application is available as a free download from
http://www.kramerelectronics.com).
You can choose from 24 resolutions (see Figure 9).
Common resolutions 1 through 16 are predefined. Resolution 24 is Output Native
Resolution as shown in the table below.
Common Resolutions
#
Resolution Name
Resolution
1
VGA
640 x 480 @60Hz
2
720 x 480 @60Hz
3
SVGA
800 x 600 @60Hz
4
XGA
1024 x 768 @60Hz
5
1260 x 720 @60Hz
6
1360 x 768 @60Hz
7
1440 x 900 @60Hz
8
SXGA+
1400 x 1050 @60Hz
9
SXGA
1260 x 1024 @60Hz
10
WSXGA+
1680 x 1050 @60Hz
11
SXGA
1280 x 1024 @75Hz
12
HD 1080
1920 x 1080 @60Hz
13
WUXGA
1920 x 1200 @60Hz
14
UXGA
1600 x 1200 @60Hz
15
720 x 480i @60Hz
16
HD 1080
1920 x 1080i @60Hz
24
Output Native
Resolution
User-defined resolutions 17 (Label 1) through 23 (Label 7) can be selected from
the resolutions in the following table.
