SID-X3N - Tech
nical Specifications
19
19
9.1
Supported Reso
lutions
HDMI/DVI
Resolution
Refresh Rate
640 x 480p
85Hz; 75Hz; 72Hz; 60Hz; 59.95Hz
720 x 480i
30Hz
720 x 480p
60Hz
720 x 576p
50Hz
800 x 600p
85Hz; 75Hz; 72Hz; 60Hz
848 x 480p
60Hz
852 x 480p
60Hz
1024 x 768p
85Hz; 75Hz; 70Hz; 60Hz
1080 x 1920p
50Hz; 60Hz; 24Hz;
1080 x 1920i
50Hz; 60Hz;
1152 x 864p
75Hz
1280 x 768p
60Hz
1280 x 800p
60Hz
1280 x 960
60Hz
1280 x 1024p
75Hz; 60Hz
1360 x 768p
60Hz
1366 x 768
60Hz; 50Hz
1400 x 1050p
60Hz
1440 x 900p
60Hz
1600 x 900p
60Hz
1600 x 1200p
60Hz
1680 x 1050p
60Hz
Display
Port
Resolution
Refresh Rate
640 x 480p
85Hz; 75Hz; 72Hz; 60Hz
800 x 600p
85Hz; 75Hz; 72Hz; 60Hz
848 x 480p
60Hz
1024 x 768p
85Hz; 75Hz; 70Hz; 60Hz
1080 x 1920i
60Hz;
1152 x 864p
75Hz
1280 x 768p
60Hz
1280 x 800p
60Hz
1280 x 960
60Hz
1280 x 1024p
75Hz; 60Hz
1360 x 768p
60Hz
1366 x 768
60Hz;
1400 x 1050
60Hz
22
24
Table of Contents
Table of Contents
4
Introduction
5
Getting Started
6
Achieving the Best Performance
6
Safety Instructions
6
Shielded Twisted Pair/Unshielded Twisted Pair
7
Recycling Kramer Products
7
Overview
8
Defining the SID-X3N Step-In Commander
10
Figure 1: SID-X3N Step-In Commander Front Panel
10
Figure 2: SID-X3N Step-In Commander Rear Panel
11
Connecting the SID-X3N
12
Figure 3: Connecting the SID-X3N Step-In Commander
12
Connecting the Remote Step-In Switch and LED
13
Figure 4: Remote Step-In Switch and LED Wiring
13
Connecting the Remote Select Switch and LED
14
Figure 5: Remote Select Switch and LED Wiring
14
Connecting the Remote Input Selection Leds
15
Figure 6: Remote Input Indicator LED Connections
15
Figure 7: Remote Input Indicator LED Wiring
15
Principles of Operation
16
Video Input Selection
16
Audio Signal Control
17
Automatic Output Shutdown
17
Operating the SID-X3N
18
Manually Selecting an Input
18
Taking Control of the Switcher Input When Connected to the VS-62H
19
Locking the EDID
19
Audio Mode Selection
19
Adjusting the UXGA Input Phase
19
Configuring the SID-X3N
20
Setting the Configuration DIP-Switch
20
Figure 8: the Configuration DIP-Switch
20
Technical Specifications
22
Supported Resolutions
23
Default EDID
25
HDMI, Displayport and DVI
25
Pc-Uxga
27
Protocol 2000
29
Syntax
29
Instruction Codes
30
Protocol 3000
32
Kramer Protocol 3000 Syntax
32
Kramer Protocol 3000 Commands
35
