Kranzle Profi 160 TST - Technical Data; Model Specifications Comparison

4
Operating press. continuously adj. 10 - 140 bar 10 - 170 bar
Nozzle size 25042 25030
Permissible overpressure 160 bar 195 bar
Water output
at 1,400 r.p.m. 11 l/min at 1,400 r.p.m. 8 l/min
Water inlet temperature max. 60 °C max. 60 °C
Suction height 2.5 m 2.5 m
Steel-weave high-pressure hose 15 m 15 m
Detergent suction ja ja
Connected load
230 V~, 14.3 A, 50 Hz 230 V~, 14.3 A, 50 Hz
Power input P 1 - 3.2 kW P 1 - 3.2 kW
Power output P 2 - 2.5 kW P 2 - 2.5 kW
Weight 41 kg 41 kg
Dim. incl. pulling handle in mm 355 x 375 x 980 355 x 375 x 980
Sound level acc. to DIN 45 635 78 dB (A) 81 dB (A)
Sound level with Dirtkiller 82 dB (A) 78 dB (A)
Acoustic power L
WA
89 dB (A) 91 dB (A)
Recoil at lance approx. 25 N approx. 32 N
Vibration at lance 2.0 m/s
2
2.0 m/s
2
Permissible tolerance for figures ± 5 % acc. to VDMA uniform sheet 24411
Kränzle Profi 160 TS T Kränzle Profi 195 TS T
Tecnical data
