Note: When adjusting counts for incorrect radii on bends:
A large change in the number of counts will produce a small
change in radius.
Slight radius bent parts-
A small change in the number of counts will produce a large
change in radius.
7. Bend a fresh bar. The measuring bend roll will probably need some fine adjustments when a new
bar that had no previous radius on it is bent.
8. When you get the correct radius with your fresh bar. Note: the count value is POS. This is the
count you want to save to memory for that bar size and radius.
