Kreg Jig K5 User Manual

www.kregtool.com
Parts
Additional Master System Parts
Your Kreg Jig
®
K5 or K5 Master System is almost ready to use right out of the box. Apply the
screw-length selection guide label to the inside of one extension lid. Place the jig on your
workbench and  t the dovetail keys on the extensions into the dovetail slots in the base. The jig
and extensions feature holes for mounting to a board.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
S
2

Kreg Jig K5 Specifications

General

Product Name	Kreg Jig K5
Category	Power Tool
Type	Pocket Hole Jig
Material Support	Yes
Dust Collection	Yes
Storage	Yes, with storage wings
Material	Nylon, steel, glass-filled nylon
Thickness Settings	1/2" to 1-1/2"
Drill Guide Compatibility	Kreg drill bits
Included Components	drill bit
Clamping Method	Over-center toggle clamp
Clamp Type	Over-center toggle clamp
