Kreg Jig K5 User Manual

800-447-8638
K5 and K5 Master System Parts
Base
Features four holes for securing the jig to a workbench or auxiliary base
Drill-guide socket
Accepts all Kreg drill guides: Micro, Standard (included), and HD
Toggle handle
Operates workpiece clamping mechanism
Clamp assembly
Powerful internal spring applies clamping pressure
Ratchet plate
Provides clamp-assembly adjustment
Ratchet release
Disengages clamp assembly from ratchet plate
Standard drill guide
Features marks for positioning the guide for different workpiece thicknesses
Locking pin
Spring-loaded pin locks the drill guide into the drill-guide socket at the selected setting
Step bit
Simultaneously drills a pilot hole and clearance hole, forming a bearing shoulder for
the screw head
Stop collar
Controls drilling depth
Hex wrench
For the stop-collar set screw
Stop-collar setting block
Ensures proper positioning of the depth collar on the drill bit
Driver bit
#2 square-drive bit 6" (152mm) long
Workpiece stop
Stop snaps into keyhole slots in the base
 Workpiecestopne-adjustmentnut
 ¼-20nuttsintohexrecessinworkpiecestop
Knurled nut
 Nylonknurlednutactsasjamnuttoxthepositionofthene-adjustmentscrew
 Fine-adjustmentscrew
 ¼-20x2½"(64mm)nylonboltthreadsintonuttoprovideno-slipneadjustment
Parts
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
3

Kreg Jig K5 Specifications

General

Product Name	Kreg Jig K5
Category	Power Tool
Type	Pocket Hole Jig
Material Support	Yes
Dust Collection	Yes
Storage	Yes, with storage wings
Material	Nylon, steel, glass-filled nylon
Thickness Settings	1/2" to 1-1/2"
Drill Guide Compatibility	Kreg drill bits
Included Components	drill bit
Clamping Method	Over-center toggle clamp
Clamp Type	Over-center toggle clamp
