Krone EasyCut F 360 Original Operation Instructions

Settings
41
Pos: 22.10 /Übersc hriften/Überschrif ten 2/A-E/Ein stellung der E ntlastungsfed ern @ 0\mod_ 1196666659447_7 8.docx @ 101 33 @ 2 @ 1
9.2 Adjusting the Compensation Springs
Pos: 22.11 /BA/Ei nstellungen/M ähwerke/EasyCu t/Bodendruck/B odendruck allg emeiner Te xtalle EC @ 0\mod_ 11966672711 81_78.docx @ 1 0190 @ @ 1
The ground pressure for the cutter bar is adjusted to local conditions by means of the
compensation springs. In order to protect the sward the load on the mowing spar must be
relieved so that it does not jump when mowing, yet does not leave any skid marks on the
ground.
Pos: 22.12 /BA/Ei nstellungen/M ähwerke/EasyCu t/Bodendruck/B odendruck ei nstellen Bild EC F 280/320/Bode ndruck einstelle nBil d EC F280/ 320/360 @ 136 \mod_1352883 434463_78.doc x@ 1211705 @ 2 @ 1
1
2
EC-145-1
EC-444-0
1
2
Fig. 19
Pos: 22.13 /BA/Ei nstellungen/M ähwerke/EasyCu t/Bodendruck/B odendruck ei nstellen Text EC 28/32 28/32CV @ 10\mod_1221 737841223_78. docx @ 136908 @ @ 1
Note
Retaining chain shorter= reduced ground pressure
Retaining chain longer= increased ground pressure
If a telescope upper suspension arm is being used (optional)
The higher the compensation springs (1) are hooked into the perforated bar (2), the lower the
pressure on the ground in the front part of the cutter bar.
If the compensation springs are hooked in too high, the mowing unit will tip towards the
rear.
or:
The lower the compensation springs (1) are hooked into the perforated bar (2), the greater the
pressure on the ground in the front part of the cutter bar.
If the compensation springs are hooked in too low, the mowing unit will have too much
weight on the ground in front.
