Maintenance
53
Pos: 24.50.10 / BA/Wartung/Mä hwerke/Öl kontrolleM ähholm Eas ycut @ 3\mo d_120472320693 0_78.docx @ 7 2428 @ @ 1
• Allow the machine to run briefly. Do not leave the driver’s cab until the cutting discs/blade
drums have come to a complete stop
EC-0-003
Fig. 28:
Check the oil level before every use
• Remove the oil level inspection screw (1) from the cutting disc hub
• The oil level must be up to the bore hole. If required, top up the oil (SAE 90)
• Screw in the oil level inspection screw (1) again and tighten securely
