ROAD OPERATIONS
90
Operating instructions • Load Carrier • 505410638-02 • 07/2019
Unhitching the central axle trailer
INFO
After uncoupling the brake lines, close off
the coupling heads and the connection
sockets for the electrical cables/power to
prevent contamination.
Position the train as straight as pos-
sible.
Apply the parking brake on the tractor
unit.
Apply the parking brake on the trailer
(see "5.9.2 Parking brake", pg.37).
Use wheel chocks to prevent the trailer
from rolling away (see "5.1 Using wheel
chocks", pg.22).
Wind down the landing leg winch until
the coupling ring is slightly lifted off the
coupling funnel (see "5.2 Landing leg
winches", pg.23).
Disconnect the supply and control
lines (see "5.6 Supply and control connec-
tions", pg.31).
Use the coupling's hand lever to move
the coupling bolts to the “opened” posi-
tion.
Slowly drive the tractor unit away in a
straight line.
Use the coupling's hand lever to move
the coupling bolts to the “closed” posi-
tion.
ü The central axle trailer is unhitched.
Hitching the turnframe trailer
Before coupling, check:
○ Is the tractor unit's permissible towing
capacity adequate for the trailer?
○ Has the permissible drawbar load
been observed?
○ Has the permitted maximum length
been observed?
○ Do the tractor unit's trailer coupling
design and the trailer's coupling eye
design match?
○ Do the position of the draw gear and
the coupling height match?
Apply the parking brake on the trailer
(see "5.9.2 Parking brake", pg.37).
Use wheel chocks to prevent the trailer
from rolling away (see "5.1 Using wheel
chocks", pg.22).
Release the front axle brake.
Move the tractor unit towards the
coupling ring, leave approx. 1 m dis-
tance.
Set the coupling ring of the draw fork
to the coupling height (see "5.4 Draw
fork", pg.27).
Use the coupling's hand lever to move
the coupling bolts to the “opened” posi-
tion.
Lock the coupling funnel in open posi-
tion.
Vacate the danger area between the
tractor unit and trailer!
Begin coupling by backing up the
tractor unit. The coupling automatically
takes place.
Apply the parking brake on the tractor
unit (see "5.9.2 Parking brake", pg.37).
Check if the coupling bolt is properly
locked into place.
Connect the supply and control lines
(see "5.6 Supply and control connections",
pg.31).
If necessary, release the height adjust-
ment device.
Remove the wheel chocks and prop-
erly secure them (see "5.1 Using wheel
chocks", pg.22).
Disengage the parking brake on the
trailer (see "5.9.2 Parking brake", pg.37).
Set the air suspension to the driving
position (see "5.10 Air suspension",
pg.41).
Carry out a departure check (see "7.1
Commissioning before each trip", pg.88).
ü The turnframe trailer is hitched and
ready for travel.
