VEHICLE OVERVIEW
Operating instructions • Load Carrier • 505410638-02 • 07/2019
17
3 Vehicle overview
The following illustrations provide an ex-
ample of the design of the central axle
trailer and the turnframe trailer in the slid-
ing curtain version and the full-tarp with
board wall version.
Fig.3-1: Central axle trailer with sliding curtain semitrailer
1 Sliding curtain superstructure
2 Rear gantry
3 Rear underrun protection
4 Axle assembly
5 Side collision protection
6 Control unit for brake system/air suspension
7 Drawbar wale
