VEHICLE OVERVIEW
18
Operating instructions • Load Carrier • 505410638-02 • 07/2019
1 2
345678
Fig.3-2: Turnframe trailer (2-axle) with sliding curtain superstructure
1 Sliding curtain superstructure
2 Rear gantry
3 Rear underrun protection
4 Axle assembly
5 Tool box (option)
6 Control unit for brake system/air suspension
7 Side collision protection
8 Draw fork
