VEHICLE OVERVIEW
Operating instructions • Load Carrier • 505410638-02 • 07/2019
19
Fig.3-3: Turnframe trailer (3-axle) with sliding curtain superstructure
1 Sliding curtain superstructure
2 Rear gantry
3 Rear underrun protection
4 Axle assembly
5 Tool box (option)
6 Control unit for brake system/air suspension
7 Side collision protection
8 Draw fork
