3
2.3 Printer Parts
Fig. 1 Top front view
Note:
The interface picture here is for reference only. Please refer to the product specification for the
interfaces availability.
Top Cover Open Lever
LED Indicator
Feed Button
Printer Top Cover
Ribbon Access Cover
Clear Window
1
2
3
4
5
6
1. USB Interface
2. Centronics Interface
3. RS-232C DB-9 Interface
4. Power Jack
5. Power Switch
6. Rear Paper Guide
Fig. 2 Rear view
