KRUPS SERIE EA9000
10
OVERALL VIEW
2.1 Description of the appliance
n The fold-out page shows a photo of the appliance. Fold out this page. The various controls of the
appliance are listed below with a brief description of them:
2
No. IDENTIFICATION FUNCTION
1 ON/OFF button To switch the appliance on and off.
2 Ground coffee button
To access the machine’s ground coffee function and to unlock
the ground coffee funnel.
3 Colour touch screen To access the recipes and other functions of the machine.
4 Removable water tank + lid Contains water for preparing recipes, cleaning and rinsing.
5 Used coffee collector Collects the used ground coffee.
6
Small drip tray and grid: can be
removed to position tall cups
To collect water or coffee that might flow out of the appliance
during/after preparation.
It can be removed to use taller cups (large recipes, caffe latte in
particular).
7 Large drip tray with metal contacts
Collects water flowing out of the appliance (when draining the
Thermoblock and hydraulic system) or water coming from the
small drip tray.
8 Steam/hot water nozzle
To produce steam to heat or froth milk.
Or
To produce hot water.
9 Steam/hot water tube
10 Steam nozzle tip
11 Steam nozzle cleaning container For automatic programmes that rinse and clean the milk nozzle.
12 Ground coffee funnel
Holds the ground coffee.
Holds the cleaning tablet during the automatic cleaning
programme.
