4 Description
14 of 68
Calio
1157.821/04-EN
4 Description
4.1 General description
▪ High-efficiency circulator pumps with continuously variable speed control
▪ Non-self-priming in-line pump with integrated permanent magnet motor and
electronic variable speed system
Pump for handling clean, non-aggressive fluids which are not chemically and
mechanically aggressive to the pump materials.
4.2 Product information as per Regulation No. 1907/2006(REACH)
For information as per chemicals Regulation (EC) No. 1907/2006 (REACH), see http://
www.ksb.com/reach.
4.3 Designation
Example: Calio 40-180
Table5: Designation key
Code Description
Calio Type series
40 Connection
25 Rp 1
30 Rp 11/4
32 DN 32
40 DN40
50 DN50
65 DN 65
80 DN80
100 DN100
180 Head H
1)
[m]
180 Head × 10
Example: 18m × 10 = 180
1) At flow rate Q = 0m³/h
